Canon TX-20 Full Auto Tonometer - Manual (Page 65)

5TypesofMeasurements
65
UsingtheRS-232CorLANconnector
Ask your sales representative or local Canon dealer to check the connectable computer,
connecting cables, setting and operation methods of the TX-20.
How to Enter the Output Settings Menu
MENU screen > Output tab > [Output]
Setting items Description
Factory
settings
Interface Set the interface for external output.
[OFF]: Turns off external output.
[LAN]: Uses LAN interface.
[RS-232C]: Uses RS-232C interface.
OFF
Settings for RS-232C
You can set the data format, transmission speed, transmission bits, parity, and stop bit in the RS-
232C menu.
How to Enter the RS-232C Menu
MENU screen > Output tab > [RS-232C]
Setting items Description
Factory
settings
Format Select the format to output measurement data.
[T-2(EACH)]: T-2 format (1 data)
[T-2(ALL)]: T-2 format (all data)
[TX-F]: TX-F format
[JMOIA]: JMOIA format
[TX-20]: TX-20 format
TX-20
Baud rate Select transmission speed.
[300/600/1200/2400/4800/9600/19200]: Transmission speeds
9600
Bit Select transmission bit.
[7/8]: Transmission bit
8
Parity Select parity.
[ODD/EVEN/NONE]: Parity
NONE
Stop Bit Select stop bit.
[1/2]: Stop bit
1
Settings for LAN
You can set the DHCP, IP address, subnet mask, default gateway, user name, password, and IP
address of the connected computer, DNS server, and name of data folder. You can also enable
transmission of image data and do connection tests.
