5TypesofMeasurements
55
6
Delete a character.
Use the CHIN REST button and the measurement unit vertical movement ring to move the selection
cursor to the position of
(ID delete command).
Press the measurement button one time to delete “2” and move “C” one space to the left.
The “2”
disappears.
Select .
7
Decide on the position to add text.
Move the ID cursor to the character to the right of the place to add text.
The procedure in steps 7 to 8 is explained using an example of adding an “@” between the “1” and “C”.
In this example, the cursor is already at the position of the “C”, so there is no operation.
Toaddtexttothefront
Move the ID cursor to the first character.
8
Add a character.
Use the CHIN REST button and the measurement unit vertical movement ring to select [@]. Press the
measurement button one time to add the “@” in front of the “C”.
The “@” is
added.
Select [@].
