4BasicOperation
39
3
Connect an RS-232C cable or LAN cable to send measurement results to an external
device.
• You cannot use the RS-232C and LAN connections at the same time. Use only one.
• Use a cross cable for the RS-232C cable.
• Ask your sales representative or local Canon dealer to set the connections for RS-232C and
LAN.
LAN connector
RS-232C
connector
4
Connect the power cord.
Power cord
5
Insert the power plug all the way into an AC outlet.
Do not replace the paper unless the TX-20 is correctly installed in a flat location as specified.
Changing the paper while the TX-20 is not level may cause a paper jam.
