REV. B –3–
ADuC812
ADuC812BS
Parameter V
DD
= 5 V V
DD
= 3 V Unit Test Conditions/Comments
ADC CHANNEL SPECIFICATIONS
DC ACCURACY 3, 4
Resolution 12 12 Bits
Integral Nonlinearity ±1/2 ±1/2 LSB typ f
SAMPLE
= 100 kHz
±1.5
LSB max f
SAMPLE
= 100 kHz
±1.5 ±1.5
LSB typ f
SAMPLE
= 200 kHz
Differential Nonlinearity
±1 ±1
LSB typ f
SAMPLE
= 100 kHz. Guaranteed No
Missing Codes at 5 V
CALIBRATED ENDPOINT ERRORS 5, 6
Offset Error
±5
LSB max
±1 ±2
LSB typ
Offset Error Match 1 1 LSB typ
Gain Error
±6
LSB max
±1 ±2 LSB typ
Gain Error Match 1.5 1.5 LSB typ
USER SYSTEM CALIBRATION 7
Offset Calibration Range
±5 ±5
% of V
REF
typ
Gain Calibration Range ±2.5 ±2.5 % of V
REF
typ
DYNAMIC PERFORMANCE f
IN
= 10 kHz Sine Wave
f
SAMPLE
= 100 kHz
Signal-to-Noise Ratio (SNR) 8 70 70 dB typ
Total Harmonic Distortion (THD) –78 –78 dB typ
Peak Harmonic or Spurious Noise –78 –78 dB typ
ANALOG INPUT
Input Voltage Ranges 0 to V
REF
0 to V
REF
Volts
Leakage Current
±10 µA max
±1 ±1 µA typ
Input Capacitance 9 20 20 pF max
TEMPERATURE SENSOR 10
Voltage Output at 25
°C
600 600 mV typ Can vary significantly (>
±20%)
Voltage TC –3.0 –3.0 mV/
°C typ
from device to device
DAC CHANNEL SPECIFICATIONS
DC ACCURACY 11
Resolution 12 12 Bits
Relative Accuracy
±3 ±3
LSB typ
Differential Nonlinearity
±0.5 ±1
LSB typ Guaranteed 12-Bit Monotonic
Offset Error ±60 mV max
±25 ±25 mV typ
Full-Scale Error
±30
mV max
±10 ±10
mV typ
Full-Scale Mismatch
±0.5 ±0.5
% typ % of Full-Scale on DAC1
ANALOG OUTPUTS
Voltage Range_0 0 to V
REF
0 to V
REF
V typ
Voltage Range_1 0 to V
DD
0 to V
DD
V typ
Resistive Load 10 10 k
Ω typ
Capacitive Load 100 100 pF typ
Output Impedance 0.5 0.5
Ω typ
I
SINK
50 50 µA typ
SPECIFICATIONS
1, 2
(AV
DD
= DV
DD
= 3.0 V or 5.0 V
؎10%, REF
IN
/REF
OUT
= 2.5 V Internal Reference, MCLKIN = 11.0592 MHz,
f
SAMPLE
= 200 kHz, DAC V
OUT
Load to AGND; R
L
= 2 k
⍀, C
L
= 100 pF. All specifications T
A
= T
MIN
to T
MAX
, unless otherwise noted.)
