core. This mode allows the ADuC812 to capture a contiguous
sample stream at full ADC update rates (200 kHz).
A typical DMA Mode configuration example.
To set the ADuC812 into DMA mode a number of steps must
be followed.
1. The ADC must be powered down. This is done by ensuring
MD1 and MD0 are both set to 0 in ADCCON1.
2. The DMA Address pointer must be set to the start address of
where the ADC Results are to be written. This is done by
writing to the DMA mode Address Pointers DMAL, DMAH,
and DMAP. DMAL must be written to first, followed by
DMAH and then by DMAP.
3. The external memory must be preconfigured. This consists
of writing the required ADC channel IDs into the top four
bits of every second memory location in the external SRAM
starting at the first address specified by the DMA address
pointer. As the ADC DMA mode operates independent from
the ADuC812 core it is necessary to provide it with a stop
command. This is done by duplicating the last channel ID to
be converted followed by “1111” into the next channel selec-
tion field. A typical preconfiguration of external memory is
as follows.
1 1 1 1
0 0 1 1
0 0 1 1
1 0 0 0
0 1 0 1
0 0 1 0
00000AH
000000H
STOP COMMAND
REPEAT LAST CHANNEL
FOR A VALID STOP
CONDITION
CONVERT ADC CH#3
CONVERT TEMP SENSOR
CONVERT ADC CH#5
CONVERT ADC CH#2
Figure 11. Typical DMA External Memory Preconfiguration
4. The DMA is initiated by writing to the ADC SFRs in the
following sequence.
a. ADCCON2 is written to enable the DMA mode. i.e.,
MOV ADCCON2, #40H; DMA Mode enabled
b. ADCCON1 is written to configure the conversion time
and power up of the ADC. It can also enable Timer 2
driven conversions or External Triggered conversions if
required.
c. ADC conversions are initiated. This is done by starting
single/continuous conversions, starting Timer 2 running
for Timer 2 conversions or by receiving an external trigger.
When the DMA conversions are completed, the ADC interrupt
bit ADCI is set by hardware and the external SRAM contains
the new ADC conversion results as shown below. It should be
noted that no result is written to the last two memory locations.
When the DMA mode logic is active it takes the responsibility of
storing the ADC results away from both the user and ADuC812
core logic. As it writes the results of the ADC conversions to
external memory, it takes over the external memory interface
from the core. Thus, any core instructions which access the external
memory while DMA mode is enabled will not get access to it. The
core will execute the instructions and they will take the same time
to execute but they will not gain access to the external memory.
NO CONVERSION
RESULT WRITTEN HERE
CONVERSION RESULT
FOR ADC CH#3
CONVERSION RESULT
FOR TEMP SENSOR
CONVERSION RESULT
FOR ADC CH#5
CONVERSION RESULT
FOR ADC CH#2
1 1 1 1
0 0 1 1
0 0 1 1
1 0 0 0
0 1 0 1
0 0 1 0
00000AH
000000H
STOP COMMAND
Figure 12. Typical External Memory Configuration Post
ADC DMA Operation
The DMA logic operates from the ADC clock and uses
pipe-lining to perform the ADC conversions and access the
external memory at the same time. The time it takes to perform
one ADC conversion is called a DMA cycle. The actions per-
formed by the logic during a typical DMA cycle are shown in
the following diagram.
WRITE ADC RESULT
CONVERTED DURING
PREVIOUS DMA CYCLE
READ CHANNEL ID
TO BE CONVERTED DURING
NEXT DMA CYCLE
CONVERT CHANNEL READ DURING PREVIOUS DMA CYCLE
DMA CYCLE
Figure 13. DMA Cycle
From the previous diagram, it can bee seen that during one DMA
cycle the following actions are performed by the DMA logic.
1. An ADC conversion is performed on the channel whose ID
was read during the previous cycle.
2. The 12-bit result and the channel ID of the conversion per-
formed in the previous cycle is written to the external memory.
3. The ID of the next channel to be converted is read from
external memory.
For the previous example the complete flow of events is shown
in Figure 13. Because the DMA logic uses pipe-lining, it takes
three cycles before the first correct result is written out.
Micro Operation during ADC DMA Mode
During ADC DMA mode the MicroConverter core is free to
continue code execution, including general housekeeping and
communication tasks. However, it should be noted that MCU
core accesses to Ports 0 and 2 (which of course are being used
by the DMA controller) are gated “OFF” during ADC DMA
mode of operation. This means that even though the instruction
that accesses the external Ports 0 or 2 will appear to execute, no
data will be seen at these external Ports as a result.
The MicroConverter core can be configured with an interrupt to
be triggered by the DMA controller when it had finished filling
the requested block of RAM with ADC results, allowing the
service routine for this interrupt to post process data without
any real-time timing constraints.
The Offset and Gain Calibration Coefficients
The ADuC812 has two ADC calibration coefficients, one for offset
calibration and one for gain calibration. Both the offset and gain
calibration coefficients are 14-bit words, located in the Special
Function Register (SFR) area. The offset calibration coefficient
is divided into ADCOFSH (6 bits) and ADCOFSL (8 bits) and
