FUTEK IPM52x (D520) Digital Display - Manual (Page 32)

31
• Resolution - 16 bit D/A
• Located on the option/top printed circuit board
FEATURE P:
• Excitation supplies of:
„ 24VDC @150mA
Accuracy: .5%
ƒ
10VDC @200mA supply
Accuracy: .5% (adjustable)
• Located on the option/top printed circuit board
FEATURE T:
• Serial RS-232C Communication.
• Configuration of 9600 baud, No Parity Check, 8 DATA
Bits, with CTS handshaking available.
FEATURE U:
• Serial RS-485 Communication.
• Multi drop full RS485 addressable to 99.
SECTION 5 SPECIFICATIONS:
±20 mA +/- 30 mV +/- 100 mV +/- 200 mV +/- 2V ±10V
Accuracy 0.02% 0.02% 0.02% 0.02% 0.02% 0.02%
Zero Drift autozero Autozero Autozero autozero autozero autozero
Span Drift 10 ppm/°C 10 ppm/°C 10 ppm/°C 10 ppm/°C 10 ppm/°C 10 ppm/°C
Input
