FUTEK IPM52x (D520) Digital Display - Manual (Page 18)

SECTION 3.6: MAIN PROGRAMMING
BRANCHES
17
Chan1,Chan2,
Chan3
setup routines and
calibrations are
under
this main menu.
Run Mode
Press the
"ENTER" for
4 Sec.
SEL CH
To move Side ways in the chart
below press the (SELECT) button.
To move down through the chart press
the (ENTER) key.
CHAn
OutPut DiSPlY SPEC
Flashes
SEtuP/COdE
Alarms,Analog
Ouput,
Setup are under this
menu.
Update Rates,
Filter,
and Snap functions
are set under this
menu.
Quick Access F1-F4,
keys, Remote R1-R4
inputs, 20pt
Linearization,Peaks
1&2 ,Access
Code,Default settings.
See back page
for
complete Flow
Chart.
"F1"
Display
Channel
#1
Press &
release
"ENTER"
For more
Description
see Sec.
3.8
For more
description
see Sec.
3.9
For more
description
see Sec.
3.10
For more
description
see Sec.
3.7
"F2"
Display
Channel
#2
"F3"
Display
Channel
#3
Main
Programming
Branches
