Totalizer Reset
The Job Totalizer can be reset by momentarily contacting the Total Reset terminal to ground or
pressing the MENU and ENTER buttons simultaneously The Grand Totalizer can be reset via selection
in the Advanced Menu or Modbus
Totalizer Preset
User can preset Job Total values
Safety
Certifications
Class I Division 1, Groups C, D; Class II, Division 1 Groups E, F, G; Class III for US and Canada Complies
with UL 913 and CSA C22 2 No 157-92
Entity
Parameters
4-20mA
Loop
V
max
= 28V DC I
max
= 26 mA
C
i
= 0 5 μF
L
i
= 0 mH
Pulse
Output
V
max
= 28V DC I
max
= 100 mA C
i
= 0 μF
L
i
= 0 mH
Reset Input
V
max
= 5V DC
I
max
= 5 mA
C
i
= 0 μF
L
i
= 0 mH
RS485
V
max
= 10V DC I
max
= 60 mA
C
i
= 0 μF
L
i
= 0 mH
Sensor
Input
V
oc
= 2 5 V
I
sc
= 1 8 mA
C = 1 5 μF
L
a
= 1 65 H
EMC
2004/108/EC
Accuracy
0 05%
Response Time
1…100 seconds response to a step change input, user adjustable
Environmental
Limits
–22…158° F (–30…70° C); 0…90% humidity, non-condensing
Materials
Polycarbonate, stainless steel, polyurethane, thermoplastic elastomer, acrylic
Enclosure
Ratings
NEMA 4X/IP 66
Engineering
Units
Gallons, Liters, Oil Barrels (42 gallon), Liquid Barrels (31 5 gallon), Cubic Meters,
Million Gallons, Cubic Feet, Million Liters, Acre Feet
Rate Time
Seconds, minutes, hours, days
Totalizer
Exponents
0 00, 0 0, X1, x10, x100, x1000
K factor Units
Pulses/Gallon, Pulse/cubic meter, pulses/liter, pulses/cubic foot
