SPECIFICATIONS
LCD
Simultaneously shows Rate and Total
5 x 7 Dot Matrix LCD, STN Fluid
6 Digit Rate, 0 5 inch (12 7 mm) numeric
7 Digit Total, 0 5 inch (12 7 mm) numeric
Engineering Unit Labels 0 34 inch (8 6 mm)
Annunciators Alarm 1(
1
), Alarm 2 (
2
), Battery Level ( ), RS485 Communications ( COM )
Power
Battery 3 6V DC D size lithium cell gives up to 6 years of service life
Loop
4-20 mA, two wire, 25 mA limit, reverse polarity protected, 7 V DC loop loss
Auto switching between internal battery and external loop power;
includes isolation between loop power and other I/O
Inputs
Magnetic Pickup
Frequency Range 1…3500 Hz
Frequency Accuracy ±0 1%
Over Voltage
Protection
28V DC
Trigger Sensitivity 30 mV
p-p
(High) or 60 mV
p-p
(Low) - (selected by circuit board jumper)
Amplified Pulse Direct connection to amplified signal (pre-amp output from sensor)
Outputs
Analog 4-20 mA
4-20 mA, two-wire current loop 25 mA current limit
Totalizing Pulse
One pulse for each Least Significant Digit (LSD) increment of the totalizer
Pulse Type
Opto-isolated (Iso) open collector
transistor
Non-isolated open drain FET
(selected by circuit board jumper)
Maximum Voltage 28V DC
Maximum Current
Capacity
100 mA
Maximum Output
Frequency
16 Hz
Pulse Width 30 mS fixed
Status Alarms
(Advanced Only)
Type
Open collector transistor Adjustable flow rate with programmable dead
band and phase
Maximum Voltage 28V DC
Maximum Current 100 mA
Pull-Up Resistor: External required (2 2 K Ohm minimum, 10 K Ohm maximum)
Modbus
(Advanced Only)
Modbus RTU over RS485, 127 addressable units / 2-wire network, 9600 baud, long integer and single
precision IEEE754 formats; retrieve: flow rate, job totalizer, grand totalizer, alarm status and battery
level; write: reset job totalizer, reset grand totalizer
Data
Configuration
and Protection
Two 4-digit user selectable passwords; level one password enables Job Total reset only, level two
password enables all configuration and totalizer reset functions (Not Applicable on solar powered
units)
Totalizer Operation
Common
Functions
Monitors contain two totalizers: Job and Grand The user can enable/disable the Grand Totalizer
function If Grand Totalizer is enabled, it shares the 7-digit display line with the Job Totalizer –
dwelling between Job and Grand Grand Totalizer rollovers are displayed with a Count value that
increments at each rollover Totalizers are automatically backed up into non-volatile FLASH memory
every 20 minutes and prior to battery expiration; manually via keypad or when signaled via
Modbus (Advanced Model only)
