Advanced Endpoint Details (ORION Migratable only)
The View Advanced Endpoint Details button on the Quick Read screen becomes active when a single ORION Migratable
endpoint is being read via RF Select this button to access the options described below
Figure 44: Advanced Endpoint Details screen
OTEE: N The options described here are also available for ORION Migratable endpoints via IR from the IR Programming screen
Firmware Version Click Get to display the endpoint firmware version in the field
GPS Location Click Get to display the latitude/longitude for the endpoint if the location has been programmed
Flow Rate Study The field displays the flow study results
• Start Click to start a 7-day flow rate study
• Get Click to get the results from the flow rate study
• Save Click to save the flow rate study results
Get Extended
Status Data
Click to receive and display the full endpoint status which includes meter size, model type and units,
as well as any status alerts
Close Click to close the Advanced Endpoint Details screen
QUICK READ
Page 36 April 2014 ORION® Endpoint Utility
