IR Programming Buttons
Reading
Button Label
Displays For
Description Endpoint Technology Encoder Type
Quick Read All All Initiates an RF Quick Read for the selected endpoint
High Power CE All Forces a brief high powered signal from the endpoint to a
gateway receiver
Program/
Force Read
All All Toggles, based on the encoder type For ORION water endpoints
with an RTR, Program is used to set the endpoint odometer value
following a tamper repair With an ADE or HR-E LCD encoder or with
an E-Series meter, Force Read is used to view the real-time encoder
odometer value
Read Endpoint All All Initiates IR communication between the software and the endpoint
Radio Status
Button Label
Displays For
Description Endpoint Technology Encoder Type
Start All All Starts endpoint radio "On-Mobile Mode" is shown in the
Radio Status field
Stop All All Stops endpoint radio "Stopped" is shown in the Radio Status field
A stopped endpoint must be reprogrammed to begin transmitting
again With an ORION Migratable or Fixed Network endpoint, the
endpoint historical interval data (profile data) is cleared when the
endpoint is restarted
Pause All All Pauses endpoint transmission temporarily until a unit of water or gas
is registered "Paused" is shown in the Radio Status field
Meter Information
Button Label
Displays For
Description Endpoint Technology Encoder Type
Change ME, SE HRE, ENC,
RTR, Gas
For water meters, used to change the meter size, type and/or units of
measure For gas meters, used to change the drive circle (units, dials
and resolution), pressure and direction
CE Gas
GPS Location (ORION ME and SE only)
Button Label
Displays For
Description Endpoint Technology Encoder Type
Set GPS
Location
ME, SE All Brings up a window in which you can enter the latitude and longitude
for the endpoint
Flow Rate Study (ORION ME and SE only)
Button Label
Displays For
Description Endpoint Technology Encoder Type
Start ME, SE All Used to start the flow rate study
Get ME, SE All Used to get the results of the flow rate study
Save ME, SE All Used to save the flow rate study results Displays where the file
is saved
IR PROGRAMMING
