For the example shown in Figure 13,
“COM 5” is selected for ORION ME
RF COM.
Result: The window closes, and the
COM port you selected is displayed
on the Settings screen.
Figure 13: COM port set
4 Repeat steps 2 and 3 to set the COM port for any additional hardware connected to the laptop
When the COM ports are set, the software application is ready to use
SETTINGS
Page 14 April 2014 ORION® Endpoint Utility
