Meter Information
Field Label
Displays For
Description
Endpoint Technology
Encoder Type
Meter Size and
Type
ME, SE
ELCD, HRE,
ENC, RTR
The size and type of the meter for which the encoder
was programmed
Unit of Measure
ME, SE
ELCD, HRE,
ENC, RTR
The unit of measure as defined by the encoder: cubic meters,
cubic feet, gallons, imperial gallons or liters
Encoder Type
ME, SE
ELCD, HRE, ENC The encoder protocol
Dials
ME, SE
ELCD, HRE, ENC The encoder dial resolution as reported from the encoder
Reverse Flow
Total
ME, SE
ELCD
The total reverse flow units measured by the encoder or the
E-Series meter
Drive Circle
ME, SE, CE
Gas
Displays after initial read for gas endpoints only Provides access
to a read-only screen displaying the possible drive circles for the
gas endpoint
Direction
ME, SE
Gas
The direction for the drive gear
Pressure Comp
ME, SE, CE
Gas
The gas pressure factor
Flow Rate Study (ORION ME and SE only)
Field Label
Displays For
Description
Endpoint Technology
Encoder Type
Start Date Time
ME, SE
All
Date and time the Flow Rate Study was started Fills when Get
button is selected
Intervals
ME, SE
All
The number of five-minute Intervals collected during the Flow Rate
Study Fills when Get button is selected
Min Max Total
ME, SE
All
The Minimum and Maximum flow, and the Total counts collected
The fields fill when Get button is selected
GPS Location (ORION ME and SE only)
Field Label
Displays For
Description
Endpoint Technology
Encoder Type
Latitude
ME, SE
All
Geographic coordinate specifying north-south position of
the endpoint
Longitude
ME, SE
All
Geographic coordinate specifying east-west position of
the endpoint
Advanced Endpoint Functions (ORION ME and SE only)
Field Label
Displays For
Description
Endpoint Technology
Encoder Type
Battery Status
ME, SE
All
Visual indicator of the endpoint battery status
