Status Indicators
Box is checked when an alert is reported. The status fields that display depend on the encoder and endpoint type.
Field Label
Displays For
Description Endpoint Technology Encoder Type
Cover Removal ME, SE Gas Endpoint is reporting a potential gas meter index cover tamper
Encoder Empty Pipe ME, SE ELCD E-Series meter is reporting a no flow condition in the pipe
Encoder End of Life ME, SE ELCD Encoder or E-Series meter is reporting to the endpoint that the
encoder battery life indicator has been activated
Encoder Error ME, SE ELCD,
HRE, ENC,
Permalog
Encoder is reporting a device error to the endpoint
Encoder Programmed ME, SE ELCD Encoder or E-Series meter is reporting to the endpoint that it
has been reprogrammed via IR
Encoder Removal ME, SE ELCD Encoder is reporting a removal condition to the endpoint
Encoder Tamper ME, SE ELCD Encoder is reporting a tamper condition
Encoder Temp ME, SE ELCD Encoder or E-Series meter is reporting to the endpoint that it
senses temperatures outside the specified range
Endpoint
Programmed
ME, SE All Endpoint was programmed via IR
Index Changed ME, SE RTR and Gas Endpoint is reporting that the reading (odometer setting)
was changed
Leak ME, SE, CE HRE, ENC,
RTR, Permalog
Endpoint is reporting a potential leak condition
ELCD Encoder or E-Series meter is reporting a potential leak condition
to the endpoint
Low Battery ME, SE All Endpoint is reporting a low battery
Mobile Mode ME, SE All Endpoint is communicating in mobile mode
No Usage ME, SE, CE HRE, ENC,
RTR and Gas Endpoint is reporting a no usage condition
ELCD Encoder or E-Series meter is reporting a potential no usage
condition to the endpoint
Reverse Flow ME, SE, CE HRE, ENC
and Gas
Endpoint is reporting a reverse flow condition
ELCD Encoder or E-Series meter is reporting a reverse flow condition
to the endpoint
Sensor Error ME, SE ELCD E-Series only Meter is reporting a sensor error or meter alarm
other than empty pipe or low temp
Tamper ME, SE, CE ELCD, HRE,
ENC, RTR,
Permalog and
Gas remotes
Endpoint is reporting a tamper This condition occurs when the
wire between the encoder and the endpoint is cut or shorted, or
the encoder is not connected
OTEE: N For more information about status indicators, refer to the following documents, available at www.badgermeter.com :
• HR-E, ENC and RTR: Refer to the ORION Water Endpoint Product Data Sheet for the endpoint type
• HR-E LCD: Refer to the HR-E LCD Encoder Installation and Programming manual
• E-Series: Refer to the E-Series Ultrasonic Meters User Manuals
