Instruction Manual DO 6
4
3 PREPARATION
3.1 Inserting & Removing Rubber Boot
1) To remove meter from rubber boot, push out from the bottom edges of
meter until it is completely out of boot. Ensure that the cables of Dissolved
Oxygen electrode or temperature probe are not connected.
2) To insert meter into rubber boot, slide in from the top of meter before
pushing the bottom edges of meter down to set it into position. Lift up the
stand at the back of meter for bench top applications if necessary.
Figure 1: Inserting or removing the rubber boot
