28
7.3.10 Ranking code output (OK rank 99 or less) –– Output signal arrangement
The ranking code output signal is output when “ITEM 1”, “ITEM 2” or “ITEM 3” is selected
with [JUDG OUT] or an item bit is entered in the set mode (6).
Note: “Item” refers to “ITEM” of DEG2000. The following table shows the output
signal arrangement of the DC input/output connector (refer to ◯
15 on page
7).
Pin No. Signal name Description
11 READY Turns on in measure mode during normal operation.
12 Error
Turns on when two signals are simultaneously input and
turns off when all signals are turned off.
13 Master OK Turns on when mastering result is OK.
14 Check input signal
Turns on when input signal is received and processing is
completed, and turns off when input signal is turned off.
15 All OK
Turns on at input of measure command when all items
are OK.
16 All NG
Turns on at input of measure command when any one
item is NG.
17 Item -NG
18 +NG
19 OK1
20 OK2
21 OK4
22 OK8
23 OK16
24 OK32
25 OK64
“OK1” to “OK64” shown at left are ranking codes.
Total of ranking codes is number of ranks.
Example: When “OK2” and “OK4” are turned on, OK6.
26
27
28
29
30
31
32
33
34
35
-COM
36 -COM
Output common line: 0 V
