9
5. Specifications
Item Specification Remarks
Power supply voltage and
frequency 85 to 264 VAC, 50/60 Hz 100 VAC power cable supplied as
accessory
Power supply capacity 30 VA
Dimensions and mass 120 mm wide × 200 mm high ×
220 mm deep, 2.7 kg
Operating temperature 0 to 45 °C
Number of programs 4 (Programs 1 to 4) Programs 1 to 3 are changeable
from external input.
Input module 1. Standard
(1) Electric micrometer
(2) Air micrometer Changeable by software and
unusable simultaneously:
2 channels for air micrometer
(external) and 2 channels for
electric micrometer (internal)
2. Dedicated for air micrometer 2 channels for air micrometer
(external)
Number of measurement items 3 (Items 1 to 3)
Number of masters 2 (MAS 1 and MAS 2)
Number of input channels
(XDUCER) 4
Air micrometer
1. FS±10 µm (0.05 to 2)
2. FS±20 µm (0.1 to 2)
3. FS±50 µm (0.1 to 2)
4. FS±100 µm (0.1 to 2)
Electric micrometer
1. FS±20 µm (0.1 to 2)
2. FS±100 µm (0.1 to 2)
Indicating range (resolution)
3. FS±1000 µm (1 to 2)
Set for each program.
Resolution is available in six types
of 0.05, 0.1, 0.2, 0.5, 1, and 2.
Mastering data input Select from among four detectors
A to D (multiple choice possible).
Symbols and coefficients (-9.999
to +9.999) can be freely
combined. Set for each master.
Example:
MAS 1 = A + B + C
MAS 2 = -A + B
Operation functions Item 1 can select MAS 1 or MAS
2, Item 2 can select MAS 1, MAS
2, or Item 1, and Item 3 can select
MAS 1, MAS 2, Item 1, or Item 2
(multiple choice possible).
Symbols and coefficients (-9.999
to +9.999) can be freely
combined. Set for each item.
Example:
Item 1 = MAS 1 + MAS 2
Item 2 = -MAS 1 +MAS 2
Item 3 = Item 1 - Item 2
1. BYPASS
2. +PEAK
3. -PEAK
4. TIR
5. TIR/2
6. MAX
7. min
8. MAX - min
9. (M - m)/2
10. (M + m)/2 Measuring functions
11. ABS
Set for each item.
