27
7.3.9 Ranking output (OK rank 39 or less) –– Output signal arrangement (option)
The ranking output signal is output when “ITEM 1”, “ITEM 2” or “ITEM 3” is selected with
[JUDG OUT], or an item bit is entered in the set mode (6). For OK rank 16 or less, refer
to “7.3.8 Ranking output”.
Note: “Item” refers to “ITEM” of DEG2000. The following table shows the output
signal arrangement of the optional DC input/output connector (refer to ◯
16 on
page 7).
Pin No. Signal name Description
11 Item OK17
12 OK18
13 OK19
14 OK20
15 OK21
16 OK22
17 OK23
18 OK24
19 OK25
20 OK26
21 OK27
22 OK28
23 OK29
24 OK30
25 OK31
26 OK32
27 OK33
28 OK34
29 OK35
30 OK36
31 OK37
32 OK38
33 OK39
34
35
-COM
36 -COM
Output common line: 0 V
