17
(7) Data request command from PC
➀ Measured value latch (data hold) command
Transmit the command byte “E”<45H>. The instrument holds the measured value.
➁ Latch clear command
Transmit the command byte “R”<52H>. The instrument clears the measured value
hold.
➂ Measured value request
Transmit the command byte “D”<44H>. The instrument transmits the above-
mentioned data (5) to the PC.
Example
Character string
ASCII code
I T E M 1 – 2 5 . 0 – N G character-string
I T E M 2 1 2 . 5 + O K
I T E M 3 N O U S E N D T CR LF
ASCII code 49 54 45 4D 31 20 20 20 20 2D 32 35 2E 30 20 2D 4E 47 20
49 54 45 4D 32 20 20 20 20 20 31 32 2E 35 20 2B 4F 47 20
49 54 45 4D 33 20 20 20 4E 4F 20 55 53 45 20 4E 44 54 0D 0A
Example
