̶ 41 ̶
6. Display of the number of the recorded data at
CH2/ the number of detected current & voltage
data in case of Trigger Recording mode.
Pressing the Button moves to CH3.
◆ Press the Button to check max,
min and peak values with time and date
information. See P.42 <PEAK/ detected value>>.
7. Display of the number of the recorded data at
CH3/ the number of detected current & voltage
data in case of Trigger Recording Mode.
Pressing the Button moves to "RECALL".
◆ Press the Button to check max,
min and peak values with time and date
information. See P.42 <PEAK/ detected value>>.
8. checks the latest 10 recorded data.
Press the Button to check the latest
recorded data and preceding 9 data, [R01] to
[R10]. Refer to P.42 <>
9. That's all for CALL Function to call the recorded
data. Pressing the Button returns to
the window with "CALL" message; pressing the
Button closes Menu mode and gets ready
for measurement.
▼
▼
▼
