̶ 40 ̶
3. Press the Button while "CALL" is displayed
on the LCD.
4. Check of
Percentage of recorded data against memory
capacity is displayed.
* Memory block with recorded data is indicated
by the Marks: ❶❷❸. When all 3 marks are lit
up, all the Memory blocks are used. Transfer the
important data to a PC and clear the Memory to
perform next recording.
Pressing the Button proceeds to the
next.
5. Display of the number of the recorded data at
CH1/ the number of detected current & voltage
data in case of Trigger Recording mode.
◆ Pressing Button moves to CH2.
◆ Press the Button to check max, min
and peak values on CH1 with time and date
information. See P.42 <PEAK/ detected value>>.
◆ Press the Button until the indication
becomes "5:RCL" for RECALL and proceed to
step 8.
▼
▼
▼
