ALTOSONIC V
ModBus Manual 0300 rev07 E 7.30855.35.00 Page 53 of 64
Flow of path 1…5
Available as scaled integer and float, these values represent internal UFP-V units.
Sound velocity of path 1...5
Available as scaled integer and float.
The floating-point numbers represent the sound velocity in m/s, the scaled integers are scaled to
32767 ( scaled 0…32767 0...3276.7 m/s).
System Set-up warning/error number
This value contains the number of the last occurred system set-up warning or system set-up error.
System Runtime warning/error number
This value contains the number of the last occurred system runtime warning or system runtime error.
System messages 1…64
Each system message corresponds to a bit in this integer value.
If a system message occurs, the accompanying bit is set, the bit remains set until the Reset_All_Errors
Boolean is set.
The messages are numbered from the least significant bit to the most significant bit.
Integer values contains the occurred-status of 16 messages,
Long integers contain the occurred-status of 32 messages,
Proces/standard/mass Totaliser
Sum of forward and reverse for the proces/standard/mass totalisers, available as long integer and
double.
All data types represents the totaliser in Liters (volumes) or (mass) kg, the totalisers have a rollover at
1 E 9. Is resetable.
Forward proces/standard/mass Totaliser
Values for the forward totalisers, available as long integer and double. All data types represents the
forward totalisers in Liters(volumes) or (mass) kg, the totalisers have a rollover at 1 E 9.
Is resetable.
Reverse proces/standard/mass Totaliser
Values for the reverse totalisers, available as long integer and double. All data types represents the
forward totalisers in Liters(volumes) or kg(mass), the totalisers have a rollover at 1 E 9.
Is resetable.
Remaining HOLD time on real-profile sampling
In case of large flow deviation or low flow, the real-profile sampling is on hold until the flow has
stabilised. Until then no new real-profile is sampled
API: Time to update a parameter (read only)
Time remaining to update a float in the API application field. Starts at 20 seconds remaining time after
the Boolean 2201 API enable writing data and counting down to 0 seconds. When at 0 seconds the
Boolean 2201 will reset (0) and it is not possible to write to the application field.
API: Correction type
The type of correction to calculate the standard volume and/or mass.
0: Disable, no standard volume or mass will be calculated.
1: Standard volume/mass by API 2540
2: Mass measurement by process density (measured by densito meter)
