B3, logbooks

B4, information

5.6.3 Menu C, setup

C1, measuring

Level

Designation / function

Settings / descriptions

This menu groups several functions which allow to display the corresponding actual reading.

B3.1

B3.1

B3.1

B3.1

status log

Log for information, errors and warnings.

Level

Designation / function

Settings / descriptions

This menu groups several other menus which contain device specific information.

B4.1

B4.1

B4.1

B4.1

Device serial no.

This menu shows the serial number of the device

B4.2

B4.2

B4.2

B4.2

Mainboard

This menu gives information about the main board.

1st line: ID No. of the circuit board

2nd line: software version

3rd line: production date

B4.3

B4.3

B4.3

B4.3

Sensor electronic

This menu gives information about the sensor electronic.

1st line: ID No. of the sensor

2nd line: software version

3rd line: production date

Level

Designation / function

Settings / descriptions

This menu groups several other menus in which the measuring functions can be set.

C1.1

Measuring function

This menu shows the different measurement functions: "Level", "Profile",

"Zone Tracking" and "Manual operation".

C1.2

Measuring mode

This menu shows the different measurement mode of the level

measurement and can be switched from "Depth" to "Height".

C1.3

Definition fluff

This menu shows the concentration of the fluff and can be set.

C1.4

Def. sludge blanket

This menu shows the concentration of the sludge blanket and can be set.

C1.5

Hysteresis

This function allows to set the hysteresis value of the zone tracking mode

(This menu is displayed only if zone tracking is selected in C3.1.1); Range:

0…5 g/l

C1.6

Tracking time

Definition time period the sensor is remaining in parking position, when

elapsed the sludge level will be tracked again (This menu is displayed only if

zone tracking is selected in C3.1.1); Range: 20…999 s

C1.7

Tracking position

Definition of the relative parking position of the sensor above the sludge

level (This menu is displayed only if zone tracking is selected in C3.1.1);

Range: 0.05-0.3 m

C1.8

Start signal

This menu shows the start signal for the measurement and can be selected

between "Timer" (via build in timer) or "Trigger input" (via external switch on

control input 1 and/or 2).

C1.9

Timer interval

This menu shows the timer interval for starting the measurement and can

be set in minutes. (This menu is displayed only if "Timer" is selected in C1.6.)

C1.10

Units

This menu groups several functions to define the units of the measuring

results. These units are used for all values of the related unit group on the

display (measuring screen and parameters).

C1.10.1

Height / Depth

This function allows to define the unit for level measurement. Options: m,

feet, inch, cm

C1.10.2

Temperature

This function allows to define the temperature unit. Options: °C, °F, K

C1.10.3

Concentration

This function allows to define the concentration unit. Options: g/l, mg/l
