B-8

SERIES EL 070312

B.47 [SOURce:]VOLTage:PROTection:UNDer? QUERY

VOLT:PROT:UND?

Syntax:

Short Form: [SOUR:]VOLT:PROT:UND?

Long Form: [SOURce:]VOLTage:PROTection:UNDer?

Returns: = undervoltage protection limit

Description: Indicates undervoltage protection limit.

B.48 [SOURce:]VOLTage:PROTection:UNDer:STATE[:LEVel] COMMAND

VOLT:PROT:UND:STAT 0

Syntax:

Short Form: [SOUR:]VOLT:PROT:UND:STAT[:LEV] 0
Long Form: [SOURce:]VOLTage:PROTection:UNDer:STATe[:LEVel] 0

Description: Clears undervoltage protection error. This error occurs when input voltage is less than

VOLT:PROT:UND level.

B.49 [SOURce:]VOLTage:PROTection:UNDer:STATE[:LEVel]? QUERY

VOLT:PROT:UND:STAT?

Syntax:

Short Form: [SOUR:]VOLT:PROT:UND:STAT[:LEV]?
Long Form: [SOURce:]VOLTage:PROTection:UNDer:STATe[:LEVel]?
where = 1 (undervoltage protection error occurred)

0 (undervoltage protection error has not occurred)

Description: Indicates whether an undervoltage protection error has occurred (1) or not (0).

B.50 STATus:CHANnel[:EVENt]? QUERY

STAT:CHAN?

Syntax:

Short Form: STAT:CHAN[:EVEN]?

Long Form: STATus:CHANnel[:EVENt]?

Returns: <16 bits> = the value of the Channel event register.

Description: Returns value of Channel event register. Each PFM within a chassis has three Channel registers

associated with it. Bits in the Event register are set whenever the associated condition occurs, and are
cleared only upon an explicit command, thus latching any conditions that occur. See Table B-2 for bit
assignments.

B.51 STATus:CHANnel:CONDition COMMAND

STAT:CHAN:COND

Syntax:

Short Form: STAT:CHAN:COND 0

Long Form: STATus:CHANnel:CONDition 0

Description: Resets the Channel Enable Register bits to zero.

B.52 STATus:CHANnel:CONDition? QUERY

STAT:CHAN:COND?

Syntax:

Short Form: STAT:CHAN:COND?

Long Form: STATus:CHANnel:CONDition?

Returns: <16 bits> = the value of the Channel condition register.

Description: Returns the value of the Channel Condition Register. Each PFM within a chassis has three Chan-

nel registers associated with it. The Condition register reflects the instantaneous state of that PFM.
Bits in the Event register are set whenever the associated condition occurs, and are cleared only upon
an STAT:CHAN:COND 0 command, thus latching any conditions that occur. See Table B-2 for bit
assignments.

TABLE B-2. CHANNEL STATUS CONDITION,

ENABLE, AND EVENT REGISTER BITS

CONDITION

NU

PS

OV

NU

OT

OP

NU OC VF

BIT

14-15

13

12

5 - 11

4

3

2

1

0

VALUE

16384-

32768

8192 4096

32-2048

16

8

4

2

1

NU -

NOT USED

OC

OVERCURRENT

OP

OVERPOWER

OT

OVERTEMPERATURE

OV

OVERVOLTAGE

PS

PROTECTION SHUTDOWN

VF

VOLTAGE FAULT
