1.8 ACCESSORIES
Accessories for the Series EL Electronic Load are listed in Table 1-5.
1.9 OPTIONS
The G option (suffix G added to model number) includes the GPIB interface. For single units the
GPIB interface is in addition to the standard RS 232 and USB interfaces. For dual units the
GPIB interface replaces the standard RS 232 and USB interfaces.
The E Option (suffix E added to model number) includes the Ethernet (LAN) interface in addition
to the standard RS 232 and USB interfaces.
Dual Channel models are identified by a D Suffix. These models contain two identical indepen-
dent loads in one chassis.
1.10 SAFETY
There are no operator serviceable parts inside the case. Service must be referred to authorized
personnel. Using the load in a manner not specified by Kepco, Inc. may impair the protection
provided by the load. Observe all safety precautions noted throughout this manual. Table 1-6
lists symbols used on the electronic load or in this manual where applicable.
TABLE 1-5. ACCESSORIES
ITEM FUNCTION
KEPCO
PART NUMBER
RJ 22 Master/Slave cable, 1 ft.
(See Note.) Daisy chains Series EL loads with the same voltage for
parallel configurations. 118-1245
Fuse 1.5A, SB Required for units configured to run from 240V a-c
source power. 141-0031
(LittelFuse
31301.5)
Slides (pair) Allows the unit to slide out of a rack. see PAR. 2.5.2.) CS 06
Side Support bracket Pair required. Used to provide side support for EL
Load. Requires rear rail at 18-13/16 in. setback. 128-1775
NOTE: For units that use slide mounting, consult Kepco for longer cable lengths.
TABLE 1-6. SAFETY SYMBOLS
SYMBOL MEANING
CAUTION: RISK OF ELECTRIC SHOCK.
CAUTION: REFER TO REFERENCED PROCEDURE.
WARNING INDICATES THE POSSIBILITY OF BODILY INJURY OR DEATH.
CAUTION INDICATES THE POSSIBILITY OF EQUIPMENT DAMAGE.
!
