A-3

A.9

*RST — RESET COMMAND

*RST

Syntax:

*RST

Description: Causes system reset of EL Load. *RST causes the unit to be reset as follows.

• VOLT:PROT:OVE Overvoltage protection set to rated overvoltage protection limit of the

Load.

• VOLT:PROT:UND Undervoltage protection set to 0.

• CURR:PROT Current Protection set to rated overcurrent protection limit of the load. or

load system when in Master/slave operation.

• POW:PROT Power protection set to rated overpower protection of the load or load sys-

tem when in master/slave operation.

• CURR Current set to 0.

• VOLT Voltage set to maximum voltage of load.

• POW Power set to 0.

• RES Resistance set to 1000 ohms.

• COND Conductance set to .001.

• INP Input set to off.

• MODE Mode set to current.

• SYST:REPLY set to off.

No other features are affected by *RST command.

A.10 *SRE — SERVICE REQUEST ENABLE COMMAND

*SRE

Syntax:

*SRE where = value from 0 - 255 per Table A-3, except bit 6 cannot be pro-
grammed.

Description: Sets the condition of the Service Request Enable register. The Service Request Enable register

determines which events of the Status Byte Register are summed into the MSS (Master Status Sum-
mary) and RQS (Request for Service) bits. RQS is the service request bit that is cleared by a serial
poll, while MSS is not cleared when read. A “1” (1 = set = enable, 0 = reset = disable) in any Service
Request Enable register bit position enables the corresponding Status Byte bit to set the RQS and
MSS bits. All the enabled Service Request Enable register bits then are logically ORed to cause Bit 6
of the Status Byte Register (MSS/RQS) to be set.

TABLE A-3. SERVICE REQUEST ENABLE AND STATUS BYTE REGISTER BITS

CONDITION

OPER

MSS
RQS

ESB

MAV

QUES

CSUM

NU

NU

BIT

7

6

5

4

3

2

1

0

VALUE

128

64

32

16

8

4

2

1

ESB

Event Status Byte summary

MAV

Message available

MSS

Master Status Summary

NU

(Not Used)

OPER Operation

Status

Summary

QUES

QUEStionable Status Summary

RQS

Request for Service
