COMMAND DETAILS
35
50B
:MEASure:RISe Query
Description Returns the first pulse rising edge timing.
Same as: Measure key → F1~F5 → F3 (RiseTime)
Syntax < Long > < Short >
:measure:rise? :meas:ris?
Returns
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rise?
Selects Channel 1, and
then measures the
rising edge timing.
51B
:MEASure:ROVShoot Query
Description Returns rise overshoot amplitude in percentage.
Same as: Measure key → F1~F5 → F3 (ROVShoot)
Syntax < Long > < Short >
:measure:rovshoot? :meas:rovs?
Returns with % sign
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rovshoot?
Selects Channel 1, and
then measures the rise
overshoot.
52B
:MEASure:RPReshoot Query
Description Returns rise overshoot amplitude in percentage.
Same as: Measure key → F1~F5 → F3 (RPReshoot)
Syntax < Long > < Short >
GDS-1000 Programming Manual
36
:measure:rpreshoot? :meas:rpr?
Returns with % sign
Note Before using this command, select the
measurement channel. See the example below.
Example :measure:source 1
:measure:rpreshoot?
Selects Channel 1, and
then measures the rise
preshoot.
53B
:MEASure:SOURce
Set
Query
Description Selects the measurement channel.
Same as: Measure key → F1~F5 → F1, F2
Syntax < Long > < Short >
:measure:source
:measure:source?
:meas:sour
:meas:sour?
Parameter
1 ~ 2 Channel1 ~ 2
Example :measure:source 1
:measure:rprshoot?
Selects Channel 1, and
then measures the rise
preshoot.
54B
:MEASure:VAMPlitude Query
Description Returns the voltage difference between positive
and negative peak.
Same as: Measure key → F1~F5 → F3 (Vamp)
Syntax < Long > < Short >
:measure:vamplitude? :meas:vamp?
Returns
Note Before using this command, select the
measurement channel. See the example below.
