GPD-X303S Series User Manual
Command Details
ISET:
Description Sets the output current for the selected channel.
X 1= CH1, 2= CH2, (4303S: 3 = CH3, 4= CH4)
Decimal number, range 0～3.200A
Response time Minimum 10ms
Example ISET1:2.234 Sets the CH1 output current to
2.234A.
ISET?
Description Returns the output current setting.
X 1= CH1, 2= CH2, (4303S: 3 = CH3, 4= CH4)
Response time Minimum 10ms
Example ISET1? Returns the CH1 output current setting.
VSET:
Description Sets the output voltage.
X 1: CH1, 2: CH2, (4303S: 3: CH3, 4: CH4)
Decimal number, range 0～32.000V
Response time Minimum 10ms
Example VSET1:20.345 Sets the CH1 voltage to 20.345V
48
