OPERATION
5. To turn on the output (and
LED), press the output key.
6. For the master (CH1) output level and CV/CC
status, refer to the CH1 meter and indicator.
Master (CH1)
voltage level
CH1 meter reading shows the
output voltage. In the above
case, 20.0V.
Master (CH1)
current level
CH1 meter reading shows the
output current. In the above
case, 2.000A.
7. Press the CH2 key (LED
turns on) and use the
Current knob to set the slave
output current.
8. For the slave (CH2) output level and CV/CC
status, refer to the CH1/CH2 meter and CH2
indicator.
