OPERATION
CH4 Independent Mode
Background /
Connection The GPD-4303S has a rating of 5V/1A max.
Output rating 5V/1A max
No Tracking
Series/Parallel CH4 does not have tracking series/parallel mode.
The CH4 output is not affected by CH1 and CH2
modes.
Panel operation 1. Connect the load to the
front panel CH4 +/−
terminal. (the diagram
shows non-European
terminals)
4
2. Press the CH2/4 key to
switch to CH4 (The CH4
indicator will light). Use
the voltage and current
knobs to set the voltage
and current.
