PSM SERIES PROGRAMMABLE POWER SUPPLY

PROGRAMMER MANUAL

⎯ 15 ⎯

Note.
“ | ” It separates one of two or more alternative parameters.
“{}” It enclose parameters within a command string.
“[]” It indicate optional keywords or parameters.
“<>” It indicate to substitute a value or a code for the enclose parameters.

General Setting Commands

APPLy {|DEF|MIN|MAX}[,{|DEF|MIN|MAX}]

APPLy?

[SOURce:]CURRent[:LEVel][:IMMediate][:AMPLitude] {|MIN|MAX|UP|DOWN}

[SOURce:]CURRent[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]

[SOURce:]CURRent[:LEVel][:IMMediate]:STEP[:INCRement] {|DEFault}

[SOURce:]CURRent[:LEVel][:IMMediate]:STEP[:INCRement]? [DEFault]

[SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude] {|MIN|MAX}

[SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX]

[SOURce:]CURRent:PROTection[:LEVel] {|MIN|MAX}

[SOURce:]CURRent:PROTection[:LEVel]? [MIN|MAX]

[SOURce:]CURRent:PROTection:STATe {0|1|OFF|ON}

[SOURce:]CURRent:PROTection:STATe?

[SOURce:]CURRent:PROTection:TRIPped?

[SOURce:]CURRent:PROTection:CLEar

[SOURce:]CURRent:PROTection:DELay { |MIN|MAX}

**

[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] {|MIN|MAX|UP|DOWN}

[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]

[SOURce:]VOLTage[:LEVel][:IMMediate]:STEP[:INCRement] {|DEFault}

[SOURce:]VOLTage[:LEVel][:IMMediate]:STEP[:INCRement]? [DEFault]

[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude] {|MIN|MAX}

PSM SERIES PROGRAMMABLE POWER SUPPLY

PROGRAMMER MANUAL

⎯ 16 ⎯

[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX]

[SOURce:]VOLTage:PROTection[:LEVel] {|MIN|MAX}

[SOURce:]VOLTage:PROTection[:LEVel]? [MIN|MAX]

[SOURce:]VOLTage:PROTection:STATe {0|1|OFF|ON}

[SOURce:]VOLTage:PROTection:STATe?

[SOURce:]VOLTage:PROTection:TRIPped?

[SOURce:]VOLTage:PROTection:CLEar

[SOURce:]VOLTage:RANGe {P8V|P20V|P15V|P30V|P60V|LOW|HIGH}*

[SOURce:]VOLTage:RANGe?

MEASure[:SCALar][:VOLTage][:DC]?

MEASure[:SCALar]:CURRent[:DC]?

OUTPut[:STATe]{0|1|OFF|ON}

OUTPut[:STATe]?

* P8V and P20V are for PSM-2010, P15V and P30V are for PSM-3004,

P30V and P60V are for PSM-6003.

** The range of the Delay time can be set at 0.0~10.0 sec.

z Trigger Commands

TRIGger[:SEQuence]:DELay {|MIN|MAX}

TRIGger[:SEQuence]:DELay?

TRIGger[:SEQuence]:SOURce {BUS|IMMediate}

TRIGger[:SEQuence]:SOURce?

INITiate[:IMMediate]

*TRG
