PSM SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 41 ⎯
When the panel displays the protective message, no further setting can be
accepted by the device. Uses this command to clear the displayed messages
in order to execute further setting.
Examples:
:VOLTage:PROTection:CLEar
:VOLTage:RANGe
Function:
Set output range..
Syntax:
:VOLTage:RANGe {P8V|P20V|LOW|HIGH} (for PSM-2010)
:VOLTage:RANGe {P15V|P30V|LOW|HIGH} (for PSM-3004)
:VOLTage:RANGe {P30V|P60V|LOW|HIGH} (for PSM-6003)
Examples:
:VOLTage:RANGe P8V set the range to 8V/20A(PSM-2010)
:VOLTage:RANGe HIGH set the range to 20V/10A(PSM-2010)
When set to 8V/20A range (or any other range), the maximum
programmable voltage and current are limited to a specific value (Please
refer to Table1-1, Table1-2 and Table1-3). “P8V” or “LOW” is for the
range of 8V/20A while “P20V” or ”HIGH” for the range of 20V/10A.
:VOLTage:RANGe?
Function:
Query output range..
Syntax:
:VOLTage:RANGe?
PSM SERIES PROGRAMMABLE POWER SUPPLY
PROGRAMMER MANUAL
⎯ 42 ⎯
Examples:
:VOLTage:RANGe? returns the currently selected range.
The returned parameter for the PSM-2010 will be “P8V” or “P20V”.
The returned parameter for the PSM-3004 will be “P15V” or “P30V”.
The returned parameter for the PSM-6003 will be “P30V” or “P60V”.
:OUTPut
Function:
Set or query the output state.
Syntax:
OUTPut:STATe {0|1|OFF|ON}
OUTPut:STATe?
Examples:
OUTPut:STATe 1(or “ON”) enables the power supply output.
If the power supply output is disabled, OUTPut:STATe? will return 0.
z STATUS COMMANDS
STATus:OPERation:CONDition?
Function:
Return the contents of the OPERation register. The programmable power
supplies, however, do not use the OPERation register to report any
conditions.
Syntax:
STATus:OPERation:CONDition?
