PSM SERIES PROGRAMMABLE POWER SUPPLY

PROGRAMMER MANUAL

⎯ 29 ⎯

0-15V/7A Range

0-30V/4A Range

Programming Range

0V to15.45V

0V to 30.9V

MAX Value

15.45V

30.9V

MIN Value

0V

0V

DEFault Value

0V

0V

*RST Value

0V

MAX Ovp Value

32V

Voltage

MIN Ovp Value

0V

Programming Range

0A to 7.21A

0A to 4.12A

MAX Value

7.21A

4.12A

MIN Value

0A

0A

DEFault Value

7A

4A

*RST Value

7A

MAX Ocp Value

7.7A

Current

MIN Ocp Value

0A

Table1-2. PSM-3004 Programming Ranges

0-30V/6A Range

0-60V/3A Range

Programming Range

0V to 30.9V

0V to 61.8V

MAX Value

30.9V

61.8V

MIN Value

0V

0V

DEFault Value

0V

0V

*RST Value

0V

MAX Ovp Value

65V

Voltage

MIN Ovp Value

0V

Programming Range

0A to 6.18A

0A to 3.4A

MAX Value

6.18A

3.4A

MIN Value

0A

0A

DEFault Value

6A

3A

*RST Value

6A

MAX Ocp Value

6.6A

Current

MIN Ocp Value

0A

Table1-3. PSM-6003 Programming Ranges

PSM SERIES PROGRAMMABLE POWER SUPPLY

PROGRAMMER MANUAL

⎯ 30 ⎯

:CURRent

Function:
Set the output current value.

Syntax:

:CURRent {|MIN|MAX|UP|DOWN}

1)

The range is from 0.0000 through 20.6000(PSM-2010

Please refer to Table1-1, Table1-2 and Table1-3.

2)

MIN is for 0.0000 while MAX for 20.6000(PSM-2010). Please refer to

Table1-1, Table1-2 and Table1-3.

3)

Up is for the current with one value increasing while down for the

current with one value decreasing. The value is set by the command of
CURRent:STEP.

Examples:

:CURRent

2.0 sets the current limit to 2.0000 amps(PSM-2010).

:CURRent MAX

sets the current limit to 20.6000(PSM-2010) amps.

:CURRent:STEP 0.1;CURRent UP

is for Current to increase 0.1 amps.

:CURRent?

Function:
Query the output current value.

Syntax:

:CURRent? [MIN|MAX]

Returns:

Scientific mark
