FOR UNITED KINGDOM ONLY
NOTE: This lead/appliance must only be wired by competent person.
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the following code:
Green/ Yellow: Earth
Blue: Neutral
Brown: Live (Phase)
As the colours of the wires in main leads may not correspond with the colours marking identified in your plug/appliance,
proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth terminal marked with the letter E or by the
earth symbol or coloured Green or Green & Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured Blue or
Black.
The wire which is coloured Brown must be connected to the terminal marked with the letter L or P or coloured Brown or
Red. If in doubt, consult the instructions provided with the equipment or contact the supplier.
This cable/appliance should be protected by a suitably rated and approved HBC mains fuse: refer to the rating information
on the equipment and/or user instructions for details. As a guide, cable of 0.75mm
2 should be protected by a 3A or 5A fuse.
Larger conductors would normally require 13A types, depending on the connection method used.
