GW Instek PEL-300 User Manual
Page 10
7
1
POWER
:
“▃” -- power is on; “▉” -- power is off.
2
C.C. MODE
:
To set operation in constant current mode.
3
C.V. MODE
:
To set operation in constant voltage mode.
4
C.R. MODE
:
To set operation in constant resistance mode.
5
RCL V
:
To recall the previous batch of memorized data.
6
RCL W
:
To recall the next batch of memorized data.
7
STEP V
:
To add a STEP value to the values of pre-set voltage, current and resistance.
8
STEP W
:
To subtract a STEP value from the values of pre-set voltage, current and resistance.
9
SW ON/OFF
:
To switch on/off dynamic operational mode.
10
AUTO
:
To execute automatically based on pre-set data (under LOAD ON status ONLY).
11
LOAD ON/OFF
:
Turn on/off LOAD function.
12
SHIFT
:
To shift and proceed secondary functions.
(1) SHIFT + C.C. MODE(Over Load Reset): To cancel overload protection.
(2) SHIFT + LOCAL(ADDR): To set location of GPIB.
(3) SHIFT + RCL V (STO): To save current data in memory.
(4) SHIFT + RCL W(RCL): To recall data from memory, or to retrieve the number of starting batch and ending
batch, and the times of execution of the memory that will be applied.
(5)SHIFT + AUTO (DLY): To set the time of execution.
(6)SHIFT + V.I.R. SET(V.I.R. STEP): To set the step value of voltage, current, and resistance.
