GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ 8 ⎯
3-3.Environment
The normal ambient temperature range of this instrument is from 0 ° to 40°C
(32 ° to 104°F). To operate the instrument over this specific temperature range
may cause damage to the circuits.
Do not use the instrument in a place where strong magnetic or electric field
exists as it may disturb the measurement.
3-4.Equipment Installation, and Operation
Ensure there is proper ventilation for the vents in the oscilloscope case. If the
equipment is used not according to the specification, the protection provided
by the equipment may be impaired.
3-5.CRT Intensity
To prevent permanent damage to the CRT phosphor, do not make the CRT
trace brighten excessively or leave the spot stay for an unreasonably long time.
3-6.Withstanding Voltages of Input Terminals
The withstanding voltages of the instrument input terminals and probe Input
terminals are shown in the following table. Do not apply voltages higher than
these limits.
Input terminal Maximum input voltage
CH1, CH2, inputs 400V (DC + AC peak)
EXT TRIG input 400V (DC + AC peak)
Probe inputs 600V (DC + AC peak)
Z AXIS input 30V (DC + AC peak)
CAUTION. To avoid damaging the instrument, do not apply
input voltages of the frequency over 1 kHz to the instrument.
GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ 9 ⎯
4. PANEL INTRODUCTION
After the instrument is switched on, all the important settings are displayed in
the readout. The LED’s located on the front panel assist operation and indicate
additional information. Incorrect operation and the electrical end positions of
control knobs are indicated by a warning beep.
All of the pushbuttons, VOLTS/DIV control knobs, TIME/DIV control knobs
are electronically selected, and their functions and settings can therefore be
stored.
The front panel is subdivided into four sections:
z Display controls
z Vertical controls
z Horizontal controls
z Trigger controls
