GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ ⎯ v
Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
No.7-1, Jhongsing Road, Tucheng City, Taipei County 236, Taiwan
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.
No.69 Lushan Road, Suzhou New District Jiangsu, China.
declares that the below mentioned product
GOS-6051/6050, GOS-6031/6030
are herewith confirmed to comply with the requirements set out in the Council Directive on
the Approximation of the Law of Member States relating to Electromagnetic Compatibility
(89/336/EEC, 92/31/EEC, 93/68/EEC) and Low Voltage Equipment Directive
(73/23/EEC, 93/68/EEC).
For the evaluation regarding the Electromagnetic Compatibility and Low Voltage
Equipment Directive, the following standards were applied:
◎ EMC
EN 61326-1: Electrical equipment for measurement, control and laboratory use –– EMC
requirements (1997+A1: 1998)
Conducted and Radiated Emission
EN 55011: 1998 Group I class A Electrostatic Discharge
IEC 61000-4-2: 1995
Current Harmonic
IEC 61000-3-2: 1995 Radiated Immunity
IEC 61000-4-3: 1995
Voltage Fluctuation
IEC 61000-3-3: 1994 Electrical Fast Transients
IEC 61000-4-4: 1995
-------------------------
Surge Immunity
IEC 61000-4-5: 1995
-------------------------
Conducted Susceptibility
IEC 61000-4-6: 1996
-------------------------
Power Frequency Magnetic Field
IEC 61000-4-8: 1993
-------------------------
Voltage Dips/ Interrupts
IEC 61000-4-11: 1994
◎ Safety
Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC
Safety Requirements
IEC/EN 61010-1: 2001
GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ 1 ⎯
1.PRODUCT INTRODUCTION
1-1. Description
The GOS-6051/50/31/30 series are 50MHz/30MHz, two-channel, portable
oscilloscopes for general purpose use. A microprocessor-based operating system
controls most of the functions of the instrument, including cursor readout and
digitized panel setting. On-screen alphanumeric readout and cursor function for
voltage, time and frequency measurement provide extraordinary operational
convenience. It also has the function of auto measurement for frequency and
counter. Ten different user defined instrument settings can be saved and recalled
without restriction.
The vertical deflection system has two input channels. Each channel has 14 basic
deflection factors from 1mV to 20V per division. The horizontal deflection
system provides sweep time from 0.5s to 0.2μs per division. The trigger system
provides stable triggering over the full bandwidth of the vertical deflection
system.
