GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ 6 ⎯
Panel Setting Display CH1/CH2 sensitivity, sweep time, trigger condition
Panel Setting Save &
Recall
10 sets.(GOS-6051/6031)
Cursor Measurement
(GOS-6051/6031)
Cursor Measurement Function: ΔV, ΔT, 1/ΔT.
Cursor Resolution: 1/25 DIV.
Effective Cursor Range: Vertical:±3 DIV,
Horizontal: ±4 DIV
CRT
READOUT
Frequency Counter
(GOS-6051/6031)
Display Digits: Max. 6-digits decimal.
Frequency Range: 50Hz~50MHz (GOS-6051)
50Hz~30MHz (GOS-6031)
Accuracy: ±0.05%: 50Hz~1kHz.
± 0.01%: 1kHz~30/50MHz.
Measuring Sensitivity: The satisfied value of the
above-mentioned Trigger Sensitivity plus 1 DIV.
(measuring source selected from CH1 or CH2 as
synchronous signal source).
Voltage AC100V, 120V, 230V ±10% selectable.
Frequency 50Hz or 60Hz.
LINE POWER
REQUIREMENT
Power Consumption Approx. 60VA, 50W(max).
Dimensions 275(W)×130(H)×370(D) mm. MECHANICAL
SPEC.
Weights 8 kg
OPERATING
ENVIRONMENT Indoor use
Altitude up to 2000 m
Ambient temperature :
To satisfy specifications : 10℃ to 35℃ ( 50
° F to 95°F )
Maximum operating ranges: 0℃ to 40℃( 32 °F to 104°F )
Relative humidity: 85% RH(max.) non condensing
Installation Category : II
Pollution degree 2
STORAGE
TEMPERATUR
E & HUMIDITY
-10 ° to 70℃, 70%RH(maximum)
ACCESSORIES
Power cord….............……….. 1
Instruction manual…………… 1
Probe (Ч1/Ч10)…………..….... 2
Measurement category I is for measurements performed on circuits not directly connected
to MAINS.
Measurement category II is for measurements performed on circuits directly connected to
the low voltage installation.
Measurement category III is for measurements performed in the building installation.
Measurement category IV is for measurements performed at the source of the low-voltage
installation.
GOS-6051/6050/6031/6030 OSCILLOSCOPE
USER MANUAL
⎯ 7 ⎯
3.PRECAUTIONS BEFORE OPERATION
3-1.Unpacking the Oscilloscope
The product has been fully inspected and tested before shipping from the
factory. Upon receiving the instrument, please unpack and inspect it to check
if there is any damages caused during transportation. If any sign of damage is
found, notify the bearer and/or the dealer immediately.
3-2.Checking the Line Voltage
The oscilloscope can be applied any kind of line voltage shown in the table
below. Before connecting the power plug to an AC line outlet, make sure the
voltage selector of the rear panel is set to the correct position corresponding to
the line voltage. It might be damaged the instrument if connected to the wrong
AC line voltage.
WARNING. To avoid electrical shock the power cord protective
grounding conductor must be connected to ground.
When line voltages are changed, replace the required fuses shown as below:
Line voltage Range Fuse Line voltage Range Fuse
100V
120V 90-110V
108-132V
T 1A250V 230V 207-250V T 0.4A250V
WARNING. To avoid personal injury, disconnect the power cord
before removing the fuse holder.
