IPDACT Module – Installationg and cabling
III-17
Doc.Dm373-I
Rev. 2.0
III - Chapter.
Installation and cabling
III - 1. Installation
The IPDACT device is designed to connect a conventional control panel,
which uses the telephone network to transmit alarms, to an IP network. The
module can be connected to a wide variety of panels although only the panels
given in the list in the appendix V.2 should be used for UL compliant
installations.
The IPDACT is installed in a separate box from the panel.
The box is shown in the following figure:
Figure 12. IPDACT Box.
The placement of the IPDACT within the box is as follows:
