411UDAC Manual — P/N 51073:E 9/20/2013

Central Station Communications

The digital communicator is capable of reporting detailed messages depending upon the Format in
use. Table 4.1 shows the data reporting structure for each of the pulsed formats as well as the
Ademco Express Formats. Ademco Express Formats allow a typical data message to be transmit-
ted to the Central Station in under 5 seconds. Pulsed formats typically require 15 to 20 seconds in
comparison. Table 4.2 defines each letter code used in Table 4.1 . See “Ademco Contact ID For-
mat Event Code Description” on page 57 for a description of the data reporting structure for
Ademco Contact ID Format.

Format #

0, 2, 4, 6, 8

Format #

3, 5, 7, 9

Format #

1, A, C

Format #

B, D

Report

3+1/4+1/Standard

4+1 Express

3+1/4+1/Expanded

4+2/Standard 4+2

Express

4+2/Expanded

Fire Alarm

SSS(S) FA

FAFAFA(FA) 2

SSSS FAFA2

SSSS FAZ

Fire Alarm Restore

SSS(S) RFA

RFARFARFA (RFA) 2

SSSS RFARFA2

SSSS RFAZ

Channel/Input Trouble

(Channel/Input Open)

SSS(S) TZ

TZTZTZ(TZ) Z

SSSS TZTZ2

SSSS TZZ

Channel/Input Trouble Restore

SSS(S) RTZ

RTZRTZRTZ(RTZ) Z

SSSS RTZRTZ2

SSSS RTZZ

System Trouble

SSS(S) TS

TSTSTS(TS) Y

SSSS TSTS2

SSSS TSY

System Trouble Restore

SSS(S) RTS

RTSRTSRTS(RTS) Y

SSSS RTSRTS2

SSSS RTSY

AC Loss

SSS(S) P

SSS(S) P
PPP(P) Z

SSSS PP2

AC Loss Restore

SSS(S) RP

RPRPRP(RP) Z

SSSS RPRP2

Fire Supervisory Condition

SSS(S) V

SSS(S) V
VVV(V) Z

SSSS VV2

SSSS VZ

Fire Supervisory Condition

Restore

SSS(S) RV

RVRVR(RV) Z

SSSS RVRV2

SSSS RVZ

Test Report

SSS(S) X

SSSS XX2

Up or Download

SSS(S) UD

SSS UDUD2

Table 4.1 Format Selection Addresses (20 and 50) Programming
