411UDAC Manual — P/N 51073:E 9/20/2013

Program Mode

Modes of Operation

4+2 Standard and 4+2 Express Formats Secondary Central Station Event
Codes

If 1, A or C is entered for address 50, the following data is automatically programmed for the Sec-
ondary Central Station phone number event codes. Enter '00' for the Setting to disable the report to
the Central Station.

Address

Description

Setting

233 - 234

Secondary # Input Channel 1 Active Event Code

235 - 236

Secondary # Input Channel 2 Active Event Code

237 - 238

Secondary # Input Channel 3 Active Event Code

239 - 240

Secondary # Input Channel 4 Active Event Code

241 - 242

Secondary # Input Channel 1 Fault Event Code

243 - 244

Secondary # Input Channel 2 Fault Event Code

245 - 246

Secondary # Input Channel 3 Fault Event Code

247 - 248

Secondary # Input Channel 4 Fault Event Code

249 - 250

Secondary # AC Fault Event Code

251 - 252

Secondary # Earth Fault Event Code

253 - 254

Secondary # Low Battery Fault Event Code

255 - 256

Secondary # No Battery Fault Event Code

257 - 258

Secondary # Phone Line 1 Voltage Fault Event Code

259 - 260

Secondary # Phone Line 2 Voltage Fault Event Code

261 - 262

Secondary # NAC Fault Event Code

263 - 264

Secondary # Charger Fault Event Code

265 - 266

Secondary # Phone Number 1 Communication Fault Event Code

267 - 268

Secondary # Phone Number 2 Communication Fault Event Code

269 - 270

Secondary # System Off Normal Fault Event Code

271 - 272

Secondary # Input Channel 1 Active Restore Code

273 - 274

Secondary # Input Channel 2 Active Restore Code

275 - 276

Secondary # Input Channel 3 Active Restore Code

277 - 278

Secondary # Input Channel 4 Active Restore Code

279 - 280

Secondary # Input Channel 1 Fault Restore Code

281 - 282

Secondary # Input Channel 2 Fault Restore Code

283 - 284

Secondary # Input Channel 3 Fault Restore Code

285 - 286

Secondary # Input Channel 4 Fault Restore Code

287 - 288

Secondary # AC Voltage Fault Restore Code

289 - 290

Secondary # Earth Fault Restore Code

291 - 292

Secondary # Low Battery Fault Restore Code

293 - 294

Secondary # No Battery Fault Restore Code

295 - 296

Secondary # Phone Line 1 Voltage Fault Restore Code

297 - 298

Secondary # Phone Line 2 Voltage Fault Restore Code

299 - 300

Secondary # NAC Fault Restore Code

301 - 302

Secondary # Charger Fault Restore Code

303 - 304

Secondary # Phone Number 1 Communication Fault Restore Code

305 - 306

Secondary # Phone Number 2 Communication Fault Restore Code

307 - 308

Secondary # System Off Normal Restore Code

309 - 310

Secondary # System Test Message

311 - 312

Secondary # System Abnormal Test Message

313 - 314

Secondary # Upload/Download Request Code

315 - 316

Secondary # Upload Successful Code

317 - 318

Secondary # Download Successful Code

319 - 320

Secondary # Upload/Download Failed Code

Table 3.5 4+2 Standard and 4+2 Express Formats - Secondary
