411UDAC Manual — P/N 51073:E 9/20/2013
39
Program Mode
Modes of Operation
All 3+1, 4+1 and 4+2 Expanded Formats Primary Central Station Event Codes
If ‘0, 2, 3, 4, 5, 6, 7, 8, 9, B or D’ is entered for address 20, the following data is automatically pro-
grammed for the Primary Central Station phone number event codes. Enter '0' for the Setting to
disable the report to the Central Station.
197 - 198
Primary # Input Channel 4 Fault Restore Code
D4
199 - 200
Primary # AC Voltage Fault Restore Code
93
201 - 202
Primary # Earth Fault Restore Code
A1
203 - 204
Primary # Low Battery Fault Restore Code
A2
205 - 206
Primary # No Battery Fault Restore Code
A3
207 - 208
Primary # Phone Line 1 Voltage Fault Restore Code
A4
209 - 210
Primary # Phone Line 2 Voltage Fault Restore Code
A5
211 - 212
Primary # NAC Fault Restore Code
A6
213 - 214
Primary # Charger Fault Restore Code
57
215 - 216
Primary # Phone Number 1 Communication Fault Restore Code
AA
217 - 218
Primary # Phone Number 2 Communication Fault Restore Code
AB
219 - 220
Primary # System Off Normal Restore Code
AF
221 - 222
Primary # System Test Message
99
223 - 224
Primary # System Abnormal Test Message
91
225 - 226
Primary # Upload/Download Request Code
71
227 - 228
Primary # Upload Successful Code
72
229 - 230
Primary # Download Successful Code
73
231 - 232
Primary # Upload/Download Failed Code
74
Address
Description
Setting
Table 3.2 4+2 Standard and 4+2 Express Formats - Primary
Address
Description
Setting
145
Primary # Input Channel 1 Active Event Code
1
146
Primary # Input Channel 2 Active Event Code
1
147
Primary # Input Channel 3 Active Event Code
1
148
Primary # Input Channel 4 Active Event Code
1
149
Primary # Input Channel 1 Fault Event Code
F
150
Primary # Input Channel 2 Fault Event Code
F
151
Primary # Input Channel 3 Fault Event Code
F
152
Primary # Input Channel 4 Fault Event Code
F
153
Primary # AC Power Fault Event Code
9
154
Primary # Earth Fault Event Code
6
155
Primary # Low Battery Fault Event Code
6
156
Primary # No Battery Fault Event Code
6
157
Primary # Phone Line 1 Voltage Fault Event Code
6
158
Primary # Phone Line 2 Voltage Fault Event Code
6
159
Primary # NAC Fault Event Code
6
160
Primary # Charger Fault Event Code
4
161
Primary # Phone Number 1 Communication Fault Event Code
6
162
Primary # Phone Number 2 Communication Fault Event Code
6
163
Primary # System Off Normal Fault Code
6
164
Primary # Input Channel 1 Active Restore Code
E
165
Primary # Input Channel 2 Active Restore Code
E
166
Primary # Input Channel 3 Active Restore Code
E
167
Primary # Input Channel 4 Active Restore Code
E
168
Primary # Input Channel 1 Fault Restore Code
D
169
Primary # Input Channel 2 Fault Restore Code
D
170
Primary # Input Channel 3 Fault Restore Code
D
Table 3.3 All 3+1, 4+1 and 4+2 Expanded Formats - Primary
