background image

2

1.

Overview

The AM-TBR process turbidimeter allows for the measurement of the turbidity of process water
on-line. The white light AM-TBR has been designed to meet the design criteria specified by the
US EPA 180.1 on turbidity measurement. The infrared AM-TBR was designed to meet the
design criteria specified in ISO 7027 and DIN 27027 for the measurement of the turbidity of a
sample. All models have long life lamps.

Some models have ultrasonic cleaning. Refer to 8.2 for more information.

A pressure regulator on the incoming line is standard on all AM-TBR models and will

reduce pressures up to 1380kPa (200 PSI) down to (104kPa) 15 PSI.

1.1. The AM-TBR Series

The AM-TBR series instruments have two light source options available, and two range options
available. The only other options are the built-in ultrasonic cleaning, and the flow alarm relay.
All units have user selectable 4-20 mA or Modbus over RS-485 outputs. Refer to the table below
to determine which factory installed options are available. Add the postfix –A to the model
number for the alarm option.

Model Number Illumination

Type

Range NTU Ultrasonic

Cleaning

AM-TBR2 WL

White Light

0-1000

No

AM-TBR2 IR

Infrared

0-1000

No

AM-TBR3 WL

White Light

0-100

Yes

AM-TBR3 IR

Infrared

0-100

Yes

AM-TBR4 WL

White Light

0-1000

Yes

AM-TBR4 IR

Infrared

0-1000

Yes


1.2. Unpacking and Inspection of the Instrument and Accessories

The table below indicates the items in the turbidimeter shipment.

Item

Quantity

AM-TBR Turbidimeter c/w Field Terminal Box & Flow Through Assembly

1

Instruction Manual

1

Desiccant Pack

1

Cuvette (Single Pack)

1*

Tubing Kit: 1-shutoff clamp
1-backpressure valve
2-connecting tubing with fittings for flow through assembly
1-drain vent screw (used in pressurized systems)

1
