Aquametrix AS Series Conductivity Sensors User Manual
Aquametrix, Aquametrix model as conductivity sensors, Water analytics

For years the MS series of epoxy body probes have been known
as the most extensive conductivity probes on the market. The
new AS series represent a major upgrade.
The AS conductivity probes feature a choice of 316 stainless
steel or graphite electrodes and Noryl shells that will satisfy just
about any industrial, power plant or laboratory application. This
technology, insures that, with reasonable maintenance, years of
drift-free performance can be expected.
Five cell constants from 0.01 to 10 are available to cover any wa-
ter sample between pure water and saline conditions. All types
are designed with a safety stop shoulder on the cell.
Integral automatic temperature compensation is standard
on all types and provides compensation to 25°C when used
with a compatible analyzer. Users can choose between a
1000 Ω RTD or 3 kΩ thernistor. Either elementi is place
to give close thermal contact with the liquid being mea-
sured to assure fast response to changing temperatur
e.
Flow-through mounting incorporates a special compression fit-
ting which allows adjustable insertion length in 3/4 inch NPT
piping or in the side of a tank. This design avoids the nuisance
of disconnecting the cell cable when installing or removing the
cell for cleaning.
Submersion mounting is achieved by reversing the direction of
the compression fitting, allowing the cell to be threaded into the
MHMSC mounting hardware. Mounting hardware is available
which includes a 2 foot length of CPVC pipe and a simple but
versatile adjustable bracket for hanging on the rim of the tank.
Ball Valve (“Hot-Tap”) types permit removal of the cell from pro-
cess piping or from tanks without shutting down the system.
They are available with in CPVC.
Features
•
316 SS or graphite Electrodes
•
Economically Priced
•
Automatic Temperature Com-
pensation
•
Adjustable Insertion Length
•
Ball Valve “Hot Tap” Types
•
Constants 0.01, 0.1, 0.5, 1.0, 10
and 50.
•
Choice of 3 kΩ thermistor or
1000 Ω RTD for automatic temper-
ature compensation.
Aquametrix Model AS
Conductivity Sensors
by
Water Analytics
AquaMetrix
100 School Street
Andover, MA 01810
978-749-9949
Toll free - 855-747-7623
www.WaterAnalytics.net
Applications
•
Cooling towers
•
High purity water applications
•
Pharmaceutical Applications
•
Reverse osmosis systems
•
Food and Beverage
