Chapter 1
______________________________________________________________________
_____________________________________________________________________________
BE6028-14
3434i SF6 Leak Detector
LumaSense Technologies A/S
Page 9 of 191
1.1 Introduction
This manual can be used in several ways. The first time users can
work their way through the examples in order to get to know this
monitoring system. The more experienced users can jump directly to
the relevant chapters in order to gain assistance, and experts can
use this manual as a reference book by using the index.
The monitor can be operated in different ways; Online Monitoring
using LumaSoft Gas Single point 7810, Online Calibration and back-
up using the Calibration Software BZ7002, Offline using the Offline
Software BZ7003 , and as a Stand-alone instrument. This manual
focuses on the Stand-alone use. For instruction in the use of BZ7002
and BZ7003 please refer to the User Manuals BE6034 and BE6035
respectively.
1.2 Online Monitoring
LumaSoft Gas Single Point 7810 is supplied with the instrument. This
is to be used for Online monitoring (PC use) please follow the
instructions in the BE6027 User Manual for online monitoring and
set-up.
1.3 PC Use BZ7002 Calibration Software
The BZ7002 Calibration Software is used for calibration of the gas
monitor from a PC. Please refer to the BZ7002 User Manual BE6034
and
1.4 PC Use BZ7003 Offline Software
Data from the display memory can be copied to the background memory
after a measurement task is performed. The BZ7003 Offline Software is
used for upload of these measurement data from the monitor to the PC in
either excel format or text format files. Please refer to the User Manual
of this manual for further instructions.
1.5 Stand-alone Use
In some situations, it may be necessary to set up without connecting
it to a PC. The procedure to do this are covered in this manual under
the Stand-alone use headings. The way these instructions are
presented is shown below:
