Chapter 12
______________________________________________________________________
_____________________________________________________________________________
BE6028-14 3434i SF6 Leak Detector LumaSense Technologies A/S
Page 142 of 191
1. Press SET-UP S3 S3.
The following text appears on the screen display:
CHECK AND / OR CHANGE SET-UP FOR FILTER A
NO YES
2. Press S3 and the following text appears on the screen display:
SELECT UA NUMBER FOR FILTER A 0988
PRESS ENTER TO CHANGE VALUE
The UA number of the filter installed in position “A” should have
already been checked (see section 12.3.2 ).
WARNING! If this number is changed all calibration data for this
filter – in all 5 filter banks – will be deleted (i.e. lost) and the filter
will have to be fully calibrated again before it can be used.
If the incorrect filter is selected, press
¿ and use p and q to
scroll through the UA numbers, until the correct UA number is
displayed.
The procedure divides here. PC users go to step 3. and Stand-alone
users go to step 4.
3. Only the Filter UA number need to be checked/changed using the
monitor’s push-buttons. All the other parameters are set when
setting up the calibration using the Calibration program.
Then exit the Calibration Set-up by pressing SET-UP.
4. Press ¿ .
The following text appears on the screen:
FILTER BANK NUMBER 1
PRESS ENTER TO CHANGE VALUE
5. Press ¿ , and use p and q to display the number of the filter bank
(1-5) where you wish the Monitor to store the calibration factors
calculated during the span calibration of this filter using this
particular gas.
6. Press
¿ .
The following text appears on the screen:
GAS A IS “_ “
PRESS ENTER TO CHANGE VALUE
