8. Install the fuse-holder and re-assemble the 3434i again.
The figure below shows the inside of the top cover of the 3434i. Note
that the front side of the cover has square flanges. Place the top
cover back in its correct position on top of the 3434i and screw in the
all screws.
2.3 Setting the USB Communication Parameters
The LumaSoft Gas 7810 application with USB communication is able
to communicate with the 3434i gas monitor through a USB cable.
BZ7002 and BZ7003 applications with USB communication are able
to communicate with the 3434i gas monitor through a USB cable .
No setup on the 3434i gas monitor is necessary in order to be able to
communicate with the 3434i gas monitor through an USB connection.
