38

Brocade MLX Series and NetIron Family Documentation Updates

53-1003301-07

IPv6 anycast filtering

1

IPv6 anycast filtering

By default all IPv6 packets with anycast address as destination will be processed. The following
command provides options to selectively enable protocols or disable all protocols.

Brocade(config)# ipv6 anycast-no-response allow tcp

Syntax: [no] ipv6 anycast-no-response [allow ]

The allow tcp | udp | icmp specifies the protocol to allow for processing.

Note:

1. The allow options can also be used as standalone commands. If ipv6 anycast-no-response is

already configured, it is modified based on the specified filters.

2. User can enable generation of TCP resets for incoming TCP packets with destination set as

anycast address, by configuring ip tcp enable-reset command. However, if ipv6
anycast-no-response command is also enabled, this command becomes void since all anycast
packets are blocked. If user requires reset to be sent for incoming anycast TCP packets, user
has to configure ipv6 anycast-no-response allow tcp to unblock the incoming TCP packets.

PBIFS extended counters

The following statistics are maintained by Stats FPGA for each of two XPPs on board

TABLE 6

Counter Type

Number of Counters per XPP
(For legacy 8x10G XMR mode)

Number of Counters per XPP
(Extended in SW5.7)

FWD/Flow Counter (Packets

512k

512k

FWD/Flow Counter (Bytes)

512k

512k

Port/Vlan/Pri Stats (Packets)

32k

64k

Port/Vlan/Pri Stats (Bytes)

32k

64k

ACL/LSP Stats (Packets)

64k

128k

ACL/LSP Stats (Bytes)

64k

128k

Port/Vlan/Pri Stats (Packets)

32k

32k

Port/Vlan/Pri Stats (Bytes)

32k

32k
