6 Brocade MLX Series and NetIron Family Documentation Updates
53-1003301-07
Telemetry Solutions
1
TABLE 2 Configured System Max Values
Configuration examples
Base-line configuration of telemetry solutions
no spanning-tree
no dual-mode-default-vlan
NOTES: Default VLAN must have TVF enabled as shown.
vlan 1 name DEFAULT-VLAN
no untagged ethe 13/1 to 13/3
transparent-hw-flooding
NOTES: Egress VLANs must have the following as shown.
1 A port present
2 TVF or TVF LAG LDB enabled
3 Port must be enabled
4 Port must be in the up state
vlan 1000 name Outer_1000
tagged ethe 13/1
transparent-hw-flooding
vlan 1001 name Outer_1001
tagged ethe 13/2
transparent-hw-flooding
vlan 1002 name Outer_1002
tagged ethe 13/3
transparent-hw-flooding
Table 0.1:
tvf-lag-lb-fid-group tvf-lag-lb-fid-pool Do not exceed value
2 512 170
2 1024 341
2 2048 682
4 512 102
4 1024 204
4 2048 409
8 512 56
8 1024 113
8 2048 227
16 512 30
16 1024 60
16 2048 120
