Wall mount installation – Brocade ICX 6450 Stackable Switches Hardware Installation Guide User Manual
Page 31
1
Rack-mounting screws
2
Cage nuts
FIGURE 23 Installing the device in a two-post rack
6.
If installing a single device only, proceed to “Powering on the system.” If installing multiple devices,
mount them in the rack, one below the other.
Wall mount installation
NOTE
You need a #2 Phillips screwdriver, a hammer, and a drill for wall mount installation.
Mounting the device to a wall is only applicable to ICX 6430-24, ICX 6430-24P, ICX 6450-24, and ICX
6450-24P devices. Brocade recommends that you wall mount the device with the port side down.
NOTE
The ICX 6430-48, ICX 6430-48P, ICX 6450-48, and ICX 6450_48P devices cannot be wall mounted.
Complete the following steps to mount the device to a wall.
Wall mount installation
Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide
29
53-1003079-01
